P10 Outdoor Led Screen
Discover top-rated Indoor LED P4.8 manufacturers in Delhi NCR. Quality assurance, and competitive prices from trusted suppliers. Brighten your space now!
Product Overview
| Brand | Khurana |
| Model No | Khurana_P4.8 |
| Application Environment | Indoor |
| Pixel Pitch | 4.8MM |
| Optimum View Distance | 4.5M-7M |
| Optimum View Angle ( Horizontal/Vertical) | 160° / 160° |
We provide our customers with Indoor Led P4.8 Exporter in Sabhapur, Jammu and Kashmir, Delhi. We can deliver products within the required tolerances as required by the customer.
Superior color performance by dot correction
High brightness, contrast ratio and wide viewing angle for clarity and easy readability
High refresh rate for flicker free
PFC (Power Factor Controller) power supply for improved efficiency, energy saving and lower operating costs IP65 rated to protect against dust and waterproof
-: Technical Specification :-
Product - P10 Outdoor Fixed
Pixel Pitch - 10mm
Pixel Configuration - SMD 3-in-1
LED Type - King light Raptor SMD 3535
Resolution (W x H) - 32 x 16 pixels
Pixel Density - 10000 pixels/sqm, 929 pixels/sqft
Brightness - Native 6,000 cd/m2
Calibrated - 5,500 cd/m2
Dimming Capability - 0~255 level
Contrast Ratio - 3500 : 1
Refresh Rate - 960 Hz
Color Processing - 12-bit
Colors - 68 billion
Viewing Angle - Horizontal 140°
Vertical - 90°
Lifetime - 100,000 hrs
Power Input - AC 100V-240V, 47 ~ 63 Hz
Power Consumption - Typ. 699 (W/cabinet) Avg. 233 (W/cabinet)
Dimensions (W x H x D) - 960 x 960 x140 mm (37.8 x 37.8 x 5.51 inch)
Weight - 41 Kg/cabinet (91 lbs/cabinet)
Operating Tempertaure - -20°~50°C (-4°~122°F)
Storage - -30°~60°C (-22°~140°F)
Relative Humidity -Operating 10%~99%
Storage - 10%~99%
Service Access - Rear
IP Grade - Front IP65 / Rear IP54
Lifespan - 100000 Hrs
MTBF - 10000 Hrs
